NC7SZ125 ON Semiconductor Datasheet PDF
Read the manufacturer datasheet for NC7SZ125 by ON Semiconductor. Search the PDF, review the main part details, and request pricing for this Logic - Buffers, Drivers, Receivers, Transceivers component without leaving the page.
Manufacturer datasheetON Semiconductor
Part Number
NC7SZ125Internal code
TCE000056779
Package
SOT-23-5
Sub Category
Logic - Buffers, Drivers, Receivers, Transceivers
Request pricing
Need pricing, availability, or lead time for this part? Send a quote request while reviewing the datasheet.
Technical summary
Key document context
NC7SZ125 from ON Semiconductor is a Logic - Buffers, Drivers, Receivers, Transceivers device in SOT-23-5 package. Use this manufacturer datasheet to review its electrical, mechanical, and ordering information.
Supply Voltage (VCC)
1.65 V to 5.5 V
Operating Temperature
-40 C to +85 C
RoHS Status
RoHS Compliant
Use the NC7SZ125 datasheet from ON Semiconductor to verify the ratings, package details, operating limits, and ordering information that apply to your design or sourcing decision.
Embedded PDF
Read the datasheet online
Loading PDF viewer...
Engineering support
Need technical help reviewing this datasheet?
If your team is stuck on package interpretation, pin-level review, missing electrical details, or qualification questions around NC7SZ125 from ON Semiconductor, contact our engineering-friendly team for a more technical discussion.
Contact a hardware engineer
You can email our engineering support contact at [email protected], or use the contact page if your question needs a broader handoff.
Pin and interface checks
Work through pin naming, signal mapping, interface expectations, and other datasheet interpretation issues.
Qualification and documentation gaps
Surface the missing specs, compliance documents, or qualification details your team still needs before approval.
NC7SZ125 cross reference and alternatives
NC7SZ125 replacement and cross-reference parts
Review mapped alternatives for NC7SZ125 from ON Semiconductor. Compare replacement type, package, lifecycle, stock, and sourcing context before RFQ or engineering approval.
Pin-to-pin optionTexas InstrumentsSOT-23-5
SN74LVC1G125DBVR
Pin-to-pin P2P drop-in for the obsolete onsemi NC7SZ125. Same SOT-23-5 footprint, same pinout (1=OE, 2=A, 3=GND, 4=Y, 5=VCC), same 3-state buffer function, similar propagation delay (~2.5 ns at 3.3 V vs ~2.0 ns for NC7SZ125). The SN74LVC1G125 family from TI is the industry-standard cross-vendor alternative and the recommended direct replacement per Z2Data and Ovaga part cross-reference. Operating voltage range is identical (1.65 V to 5.5 V). onsemi has marked NC7SZ125 as 'DISCONTINUED' in the official datasheet (Rev. 4, Page 5).
Replacement Type
Pin-to-pin option
Lifecycle status
0
key Attributes
-
Available Quantity
31,646
Pin-to-pin optionNexperiaSOT753
74LVC1G125GV
Pin-to-pin P2P drop-in for the obsolete onsemi NC7SZ125 from Nexperia. 74LVC1G125GV is the Nexperia / NXP equivalent in SOT-23-5 with identical pinout (1=OE, 2=A, 3=GND, 4=Y, 5=VCC), 1.65 V to 5.5 V VCC range, and the same CMOS 3-state buffer topology. Industry-standard cross-vendor drop-in for the TinyLogic NC7SZ family. Same 3-state output enable behavior, same quiescent current class.
Replacement Type
Pin-to-pin option
Lifecycle status
0
key Attributes
-
Available Quantity
57,121
Pin-to-pin optionTexas InstrumentsSOT-23-5
SN74AUP1G125DBVR
Pin-to-pin P2P drop-in for the obsolete onsemi NC7SZ125 from TI. SN74AUP1G125DBVR is the TI AUP-family single bus buffer gate in SOT-23-5 with identical pinout (1=OE, 2=A, 3=GND, 4=Y, 5=VCC). Listed in TI's Little Logic Guide as the cross-reference for the NC7SZ family. Lower-power variant of LVC with 0.8 V to 3.6 V VCC range; compatible at the 1.8 V to 3.3 V operating range where NC7SZ is typically deployed. Recommended when the application is in the 1.8 V core logic domain.
Replacement Type
Pin-to-pin option
Lifecycle status
0
key Attributes
-
Available Quantity
79,638
FunctionalTexas InstrumentsSOT-23-5
SN74AHC1G125DBVR
Functional alternative to the obsolete onsemi NC7SZ125. SN74AHC1G125DBVR is the TI AHC (Advanced High-Speed CMOS) single bus buffer gate in SOT-23-5 with the same pinout and 3-state output enable as NC7SZ125. AHC family operates at 2 V to 5.5 V VCC and provides higher output drive (±8 mA) than UHS NC7SZ. Same 3-state buffer function but functionally equivalent for applications where the higher drive is acceptable. Use as drop-in when design needs more output drive than the low-power NC7SZ can deliver.
Replacement Type
Functional
Lifecycle status
0
key Attributes
-
Available Quantity
66,290
Logic - Buffers, Drivers, Receivers, Transceivers
Recommended Products
Explore more parts from the same subcategory to compare fit, stock, and sourcing options.
Common questions
Datasheet questions
What is NC7SZ125?
NC7SZ125 is a Logic - Buffers, Drivers, Receivers, Transceivers component from ON Semiconductor. This page provides the manufacturer datasheet together with the core part information needed for review and sourcing.
How can I search inside the NC7SZ125 datasheet PDF?
Use the PDF search field above the viewer. Search runs inside the PDF.js reader so you can review matches without leaving the document.
Can I request a quote for NC7SZ125 while reading the datasheet?
Yes. Use the Request Quote action on this page to submit your email, quantity, and target price for NC7SZ125 from ON Semiconductor.
What package information is available for NC7SZ125?
This datasheet page lists NC7SZ125 with package reference SOT-23-5. Engineers should use the PDF to verify footprint, pin layout, and mechanical details before design or replacement decisions.
Which specifications should I check first in the NC7SZ125 datasheet?
Start with the sections covering key ratings, electrical limits, interface behavior, and the attribute group beginning with Export Classifications & Environmental. Those areas usually confirm whether NC7SZ125 fits the intended design constraints.
Can I download the NC7SZ125 datasheet PDF from this page?
Yes. This page provides a direct download for the NC7SZ125 manufacturer datasheet PDF from ON Semiconductor, while keeping the HTML datasheet page available for search and review.
